Ingersoll Rand Pt-125r

Manufacturer: Ingersoll Rand

Model: PT-125R

Year: 1995, 2001, 2006

Condition: Used

• Make and Model: Cummins B 3.3T-85​

• Gross Power: 86 horsepower (64.2 kW)

• Overall Length: 12.78 feet (3895 mm)​

• Overall Width: 6.5 feet (1980 mm)​

• Height to Top of ROPS: 10.59 feet (3225 mm)
  Wheelbase: 9.59 feet (2920 mm)​

• Operating Weight (Unballasted): Approximately 9,094 lbs (4125 kg)​

• Operating Weight (Max Ballast): Up to 16,711 lbs (7580 kg)​

• Rolling Width: 68 inches (1727 mm)​

• Tire Configuration: Four front and five rear tires, size 7.5-15, 14-ply​

• Tire Overlap: 0.5 inches (12 mm)​

• Oscillation Angle: ±3 degrees​

• Average Weight per Wheel (Unballasted): Approximately 1,010 lbs (458 kg)​

• Average Weight per Wheel (Max Ballast): Approximately 2,705 lbs (1227 kg)

• • Fuel Tank: 100.2 gallons (379 liters)​

  • Hydraulic System Fluid: 16.2 gallons (61 liters)​

  • Water Spray Tank: 100.2 gallons (379 liters)

• Hydrostatic Drive System: Provides smooth and efficient operation​

• Pressurized Water System: Ensures consistent moisture control during compaction​

• ROPS/FOPS: Equipped with Roll-Over Protective Structure and Falling Object Protective Structure for operator safety​

• Optional Equipment: Includes items such as tire scrapers, work lights, and rotating beacon lights​
